IC TRANSCEIVER FULL 2/2 24QFN LAN8720 is a Small Footprint RMII 10/100 Ethernet Transceiver with HP Auto-MDIX Support. This article mainly introduces pinout, benefit, datasheet and other detailed information about Microchip Technology LAN8720.
2225
Sep 12, 2021
Selena Attlee
ESP32 ETH LAN8720
IC TRANSCEIVER FULL 2/2 24QFN
LAN8720 is a Small Footprint RMII 10/100 Ethernet Transceiver with HP Auto-MDIX Support. This article mainly introduces pinout, benefit, datasheet and other detailed information about Microchip Technology LAN8720.
LAN8720AI-CP
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1+ | $2.29699 | $2.3 |
| 10+ | $2.16697 | $21.67 |
| 100+ | $2.04432 | $204.43 |
| 500+ | $1.9286 | $964.3 |
| 1000+ | $1.81943 | $1819.43 |
The LAN8720 is a low-power 10BASE-T/100BASE-TX physical layer (PHY) transceiver that transmits and receives on unshielded twisted-pair cable. It is available in both extended commercial and industrial temperature operating versions.
The LAN8720 Interfaces to the MAC layer using a variable voltage digital Interface via the RMII Interface The digital Interface pins are tolerant to 3.6V.
The LAN8720 implements Auto-Negotiation to automatically determine the best possible speed and duplex mode of operation. HP Auto-MDIX support allows using a direct connect LAN cable, or a cross-over path cable.
Symbol
Footprint
3D Model
• Single-Chip Ethernet Physical Layer Transceiver (PHY)
• Comprehensive FlexPWR® Technology
- Flexible Power Management Architecture
- LVCMOS Variable I/O Voltage Range: +1.6V to +3.6V
- Integrated 1.2V Regulator
• HP Auto-MDIX Support
• Miniature 24-pin QFN/SQFN Lead-Free RoHS Compliant Packages (4 x 4mm).
Microchip Technology LAN8720AI-CP technical specifications, attributes, parameters and parts with similar specifications to Microchip Technology LAN8720AI-CP.
Microchip Technology LAN8720AI-CP technical specifications, attributes, parameters and parts with similar specifications to Microchip Technology LAN8720AI-CP.
| Product Attribute | Attribute Value | |
|---|---|---|
| Factory Lead Time | 6 Weeks | |
| Mount | Surface Mount | |
| Mounting Type | Surface Mount | |
| Package / Case | 24-VFQFN Exposed Pad | |
| Number of Pins | 24Pins | |
| Weight | 67.698661mg | |
| Usage Level | Industrial grade | |
| Operating Temperature | -40°C~85°C | |
| Packaging | Tray | |
| Published | 2012 | |
| JESD-609 Code | e3 | |
| Part Status | Active | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Number of Terminations | 24Terminations | |
| Type | Transceiver |
| Product Attribute | Attribute Value | |
|---|---|---|
| Terminal Finish | Matte Tin (Sn) - annealed | |
| Voltage - Supply | 1.6V~3.6V | |
| Terminal Position | QUAD | |
| Terminal Form | NO LEAD | |
| Peak Reflow Temperature (Cel) | NOT SPECIFIED | |
| Number of Functions | 1Function | |
| Supply Voltage | 3.3V | |
| Terminal Pitch | 0.5mm | |
| Time@Peak Reflow Temperature-Max (s) | NOT SPECIFIED | |
| Base Part Number | LAN8720A | |
| Qualification Status | Not Qualified | |
| Operating Supply Voltage | 1.2V | |
| Number of Channels | 1Channel | |
| Interface | Ethernet | |
| Max Supply Current | 21mA |
| Product Attribute | Attribute Value | |
|---|---|---|
| Data Rate | 100 Mbps | |
| Protocol | RMII | |
| Number of Drivers/Receivers | 2/2Drivers/Receiver | |
| Duplex | Full | |
| Number of Transceivers | 1Transceiver | |
| Simplex/Duplex | Full Duplex | |
| Ambient Temperature Range High | 85°C | |
| Height | 1mm | |
| Length | 4.1mm | |
| Width | 4.1mm | |
| REACH SVHC | No SVHC | |
| RoHS Status | ROHS3 Compliant | |
| Lead Free | Lead Free |
Power Supply Diagram(1.2V Supplied By Internal Regulator)
Power Supply Diagram（1.2V Supplied By External Source）
| Part Number | Description | Manufacturer |
| LAN8740-EN-TRTELECOMMUNICATION CIRCUITS | Ethernet Transceiver | Microchip Technology Inc |
| LAN8710AI-EZK-TR-ABCTELECOMMUNICATION CIRCUITS | DATACOM, ETHERNET TRANSCEIVER | Microchip Technology Inc |
| LAN8740A-EN-TRTELECOMMUNICATION CIRCUITS | Ethernet Transceiver, 5 X 5 MM, 0.90 MM HEIGHT, HALOGEN FREE AND ROHS COMPLIANT, SQFN-32 | SMSC |
| LAN8710AI-EZK-TRTELECOMMUNICATION CIRCUITS | DATACOM, ETHERNET TRANSCEIVER, QCC32, 5 X 5 MM, 0.90 MM HEIGHT, ROHS COMPLIANT, QFN-32 | Microchip Technology Inc |
| LAN8710A-EZK-TRTELECOMMUNICATION CIRCUITS | Ethernet Transceiver, 1-Trnsvr, CMOS, 5 X 5 MM, 0.90 MM HEIGHT, ROHS COMPLIANT, QFN-32 | SMSC |
| LAN8740AI-ENTELECOMMUNICATION CIRCUITS | Ethernet Transceiver, 5 X 5 MM, 0.90 MM HEIGHT, HALOGEN FREE AND ROHS COMPLIANT, SQFN-32 | SMSC |
| LAN8720AI-CP-TRTELECOMMUNICATION CIRCUITS | Ethernet Transceiver, 1-Trnsvr, CMOS, 4 X 4 MM, 0.85 MM HEIGHT, ROHS COMPLIANT, QFN-24 | SMSC |
| LAN8740I-ENTELECOMMUNICATION CIRCUITS | Ethernet Transceiver | Microchip Technology Inc |
| LAN8720A-CP-TRTELECOMMUNICATION CIRCUITS | DATACOM, ETHERNET TRANSCEIVER, QCC24, 4 X 4 MM, 0.85 MM HEIGHT, ROHS COMPLIANT, QFN-24 | Microchip Technology Inc |
| LAN8710AI-EZCTELECOMMUNICATION CIRCUITS | DATACOM, ETHERNET TRANSCEIVER, QCC32, 5 X 5 MM, 0.90 MM HEIGHT, ROHS COMPLIANT, QFN-32 | Microchip Technology Inc |
• High-Performance 10/100 Ethernet Transceiver
- Compliant With IEEE802.3/802.3u (Fast Ethernet)
- Compliant With ISO 802-3/IEEE 802.3 (10BASE-T)
- Loop-Back Modes
- Auto-Negotiation
- Automatic Polarity Detection And Correction
- Link Status Change Wake-Up Detection
- Vendor Specific Register Functions
- Supports The Reduced Pin Count RMII Interface
• Power And I/Os
- Various Low Power Modes
- Integrated Power-On Reset Circuit
- Two Status LED Outputs
- Latch-Up Performance Exceeds 150mA Per EIA/JESD 78, Class II
- May Be Used With A Single 3.3V Supply
• Additional Features
- Ability To Use A Low Cost 25Mhz Crystal For Reduced BOM
• Packaging
- 24-Pin QFN/SQFN (4x4 mm) Lead-Free RoHS Compliant Package With RMII
• Environmental
- Extended Commercial Temperature Range (0°C to +85°C)
- Industrial Temperature Range Version Available (-40°C to +85°C)
• Set-Top Boxes
• Networked Printers and Servers
• Test Instrumentation
• LAN on Motherboard
• Embedded Telecom Applications
• Video Record/Playback Systems
• Cable Modems/Routers
• DSL Modems/Routers
• Digital Video Recorders
• IP and Video Phones
• Wireless Access Points
• Digital Televisions
• Digital Media Adapters/Servers
• Gaming Consoles
• POE Applications (Refer to Application Note
Microchip Technology Inc. is an American manufacturer of microcontrollers, memory and analog semiconductors. Its products include microcontrollers (PIC microcontrollers, dsPIC / PIC24, PIC32), serial EEPROM, serial SRAM, KEELOQ components, radio frequency (RF) components, thermal components, power and battery management analog components, and linear , Interface and mixed signal components. There are also some interface components including USB, ZigBee/MiWi, CANbus and Ethernet. The company is headquartered in Chandler, Arizona, and its wafer fabs are located in Tempe, Arizona and Gresham, Oregon.
Download datasheets and manufacturer documentation for Microchip Technology LAN8720AI-CP.
Download datasheets and manufacturer documentation for LAN8720AI-CP
